OPTIMAL LIGHT
LED STREET LIGHTS
Optimal Light LED Street Light Series.
60 Watt - 100 Watt - 150 Watt - 200 Watt 240 Watt 320 Watt
STREET LIGHT - TECHNICAL PARAMETERS
-
OPTIMAL LIGHT NEW LED STREET LIGHT
-
LUMEN: 130 - 150 LUMEN/ WATT
-
Input voltage : 100-277 (90-305) AC
-
LED brand PHILIPS LUMILED
-
Driver brand : MOSO / INVENTRONICS / MEANWELL
-
CRI: > 80
-
CCT : 4000K 5700K 6500K
-
Power Factor: > 0.95
-
Life Time: 100,000 HOURS
-
IP rating: IP66 & IP67
-
Surge Protection: : 10Kv 15Kv 20Kv
-
Warranty: FIVE YEARS
Description Watt CCT Lumen Voltage PF IP RATE LIFE Hrs.
OPT SL 60 WATT 60 3000K 7800 100-277 V AC 0.95 IP66 100,000 Hrs.
OPT SL 60 WATT 60 4000K 7800 100-277 V AC 0.95 IP66 100,000 Hrs
OPT SL 60 WATT 60 5700K 7800 100-277 V AC 0.95 IP66 100,000 Hrs
OPT SL 100 WATT 100 3000K 13000 100-277 V AC 0.95 IP66 100,000 Hrs
OPT SL 100 WATT 100 4000K 13000 100-277 V AC 0.95 IP66 100,000 Hrs
OPT SL 100 WATT 100 5700K 13000 100-277 V AC 0.95 IP66 100,000 Hrs
OPT SL 150 WATT 150 3000K 19500 100-277 V AC 0.95 IP66 100,000 Hrs
OPT SL 150 WATT 150 4000K 19500 100-277 V AC 0.95 IP66 100,000 Hrs
OPT SL 150 WATT 150 5700K 19500 100-277 V AC 0.95 IP66 100,000 Hrs
OPT SL 200 WATT 200 3000K 26000 100-277 V AC 0.95 IP66 100,000 Hrs
OPT SL 200 WATT 200 4000K 26000 100-277 V AC 0.95 IP66 100,000 Hrs
OPT SL 200 WATT 200 5700K 26000 100-277 V AC 0.95 IP66 100,000 Hrs
OPT SL 240 WATT 240 3000K 31200 100-277 V AC 0.95 IP66 100,000 Hrs
OPT SL 240 WATT 240 4000K 31200 100-277 V AC 0.95 IP66 100,000 Hrs
OPT SL 240 WATT 240 5700K 31200 100-277 V AC 0.95 IP66 100,000 Hrs
ANATOMY
DISTRIBUTION
DATASHEET
SENSOR - TECHNICAL SPECIFICATION
STANDARD: ANSI C136.10 & UL773
RATED VOLT: 120-277 V (APPLICABLE 105-305)
FREQUENCY: 50-60 HZ
RATED LOAD: 1000W -1800VA
TURN ON LIGHT LEVEL: 10-16 LUX
OPERTING TEMP: -40 - +70C
LIGHT SENSOR: IR FILTER PHOTOTRANSISTOR
If you have a project Please contact us for information and Quotation
